2) Visio 2003 for Database Model Diagram and UML Code Generation |
| |
|
Visio 2003 is a powerful tool for
System Development. Since the first Brainstorm meeting down to the
level of program code, including the Database Model Diagram and UML
Code Generation. The incredible resources offered by MS-Visio 2003
enables high productivities rates in system development with quality
and less time. Projetos Digitais offers a full set of consulting
services and system development method for those who manages and
support System Development Division.
Both System Development and
Software Factory Process are supported by Projetos Digitais.
|
|
• System Development |
| |
|
Working with UML Model Diagram.
Visio provides full support for creating object-oriented models of
Complex Systems. The following diagrams can be created with VISIO
2003 / UML Model Diagram: |
| |
|
Case diagram
In the early stages of a
development project, used to describe real-world activities and
motivations. You can refine the diagrams in later stages to reflect
user interface and design details. |
|
|
|
Static Structure diagram
Used to create conceptual diagrams that represent
concepts from the real world and the relationships between them,
or class diagrams that decompose a software system into its
parts. |
|
|
|
Package diagram
Used to group related elements
in a system.
One package can contain subordinate packages, diagrams, or
single elements
At right you can see the Model explorer
used to organize the packages and sub-packages. |
|
|
|
Activity diagram
Used to
describe the internal behavior of
a method and represent a flow
driven by internally generated actions. |
|
|
|
Statechart diagram Used to
show the sequence of states
an object goes through during its life. |
|
|
|
Sequence diagram Used to show
the actors or
objects
participating in an interaction and
the events they generate
arranged in a time sequence. |
|
|
|
Collaboration diagram Used to
show relationships among object roles such as the set of
messages exchanged among the objects to achieve an operation or
result. |
|
|
|
Component diagram Used to
partition a system into
cohesive components and
show the structure of the code itself. |
|
|
|
Deployment diagram Used to to
show the structure of the run-time system and communicate how
the hardware and software elements that make up an application
will be configured and deployed. |
|
|
| |
|
Yes ! It's a solid source for accelerating the Softwre
development process. |
| |
|
Besides the UML Diagrams, MS-Visio 2003 offers the following
diagrams: - COM and OLE;
- Gane-Sarson Dataflow;
- Enterprise Application;
- Jackson Software Digrams (Data structure, system
newtwork and program structure diagrams)
- ROOM diagrams. |
| |
|
• Software Factory |
| |
 |
Software Factories will benefit
from MS-VISIO 2003 in Quality and Speed.
Our expertise with corporative projects of
software development has shown that the speed increasing in getting
the final application in accompanied by quality with a final
solution near to 100% error free.
Our consulting services is based on a blend of
the Six Sigma with Microsoft Solution Framework, Windows Logo
program, Visual Studio Development Framework and other Microsoft
frameworks.
|
|
 |
|
With a team of highly
experienced consultants, both in Database Design / Data warehousing,
Systems Development / .Net and Project / Process Management, leaded
by Eng. Adriano Barbosa, we are
achieving higher level of customer satisfaction with reduced time to
deploy the final application. The solid
IT infra-structure with cutting edge computers and network systems
combined with optimized process and a calm environment, enables the
Projetos Digitais to assume key responsibilities in providing the
customer with high quality software solutions.
Click
on the right picture to explore an interface provided by Microsoft
Visio 2003 web page publishing capabilities ...
|
|
 |
|
